FRCSim Installation Tutorial with Markdown formatting

Installation Guide: FRCSim w/ Java

Written & Provided by FRC 1923: The MidKnight Inventors                                   MKI

YOU WILL NEED:

THINGS TO REMEMBER:

HOW TO DUAL-BOOT WITH UBUNTU:

Once you have downloaded the .iso file, burn the file to a USB flash drive (> 2GB)

ONCE UBUNTU IS INSTALLED:

Download WPILib (somewhat different on ubuntu) by adding the repository first.

sudo apt-add-repository ppa:wpilib/toolchain

Then you need to add java (warning: you will get a deprecation notice):

sudo add-apt-repository ppa:webupd8team/java

Run the following command - you should see all of the packages that you just installed:

sudo apt-get update

Now, paste the following command as is:

sudo apt-get install \
  git \
  libc6-i386 \
  curl \
  jstest-gtk gradle oracle-java8-installer \
  frc-toolchain meshlab cmake libprotobuf-dev \
  libprotoc-dev protobuf-compiler

Now we will edit the file /etc/environment.

sudo nano /etc/environment

Append a line with the following. This will define a system-wide variable named JAVA_HOME that references the install location of Java on your machine:

JAVA_HOME="/usr/lib/jvm/java-8-oracle"

Immediately load the /etc/environment configuration file you just created.

source /etc/environment

List the contents of your Java installation directory using your new $JAVA_HOME variable.

ls $JAVA_HOME

You should see contents like this, which means that your system is properly referencing the Java installation directory we set above.


bin LICENSE
COPYRIGHT man
db README.html
include release
javafx-src.zip src.zip
jre THIRDPARTYLICENSEREADME-JAVAFX.txt
lib THIRDPARTYLICENSEREADME.txt

INSTALLING ECLIPSE:

On the menu bar, go to: Window -> Preferences -> Java -> Installed JREs

Go to: Window -> Preferences -> General -> Workspace

Note that, if you used all the default settings, Eclipse should now be installed at $HOME/eclipse/java-oxygen/eclipse.

INSTALLING FRC ECLIPSE PLUGINS:

Name: FRC Plugins

Location: http://first.wpi.edu/FRC/roborio/release/eclipse/

INSTALLING GAZEBO:

Gazebo (the simulator software) allows you to test your robot code in a (modeled) 3D space.

curl -ssL http://get.gazebosim.org | sh

INSTALLING FRCSIM:

“With FRCSim, you should be able to finish 90% Of your programming without ever touching a RoboRIO. We want you to be able to test your code BEFORE you put in on your robot, and before the robot is even built. FRCSim allows robot code written in C++ or Java that normally runs on your RoboRIO to be run on your laptop or desktop. It connects to custom robot models in the Gazebo robot simulator.“ [3]

curl -o \
    $HOME/Downloads/simulation-2017.2.1.zip                                      http://first.wpi.edu/FRC/roborio/maven/release/edu/wpi/first/wpilib/simulation/simulation/2017.2.1/simulation-2017.2.1.zip
mkdir $HOME/wpilib/simulation

Unzip our simulation files to the directory we just created.

unzip \
    $HOME/Downloads/simulation-2017.2.1.zip \
    -d $HOME/wpilib/simulation

Create a system-wide symlink to the frcsim (FRC simulator) program.

sudo ln -s $HOME/wpilib/simulation/frcsim /usr/bin/frcsim

Create a system-wide symlink to the sim_ds (simulated driver station) program.

sudo ln -s $HOME/wpilib/simulation/sim_ds /usr/bin/sim_ds

We must manually compile the wpilib simulation plugins for FRCsim in order for the simulator to work properly on Linux.

Navigate to the $HOME/Downloads directory in your terminal.

cd $HOME/Downloads

Use git to download some wpilib code that we must compile on our machine.

git clone https://github.com/wpilibsuite/allwpilib

Navigate to the allwpilib code that we just downloaded.

cd $HOME/Downloads/allwpilib

Check out a specific version of the code we just downloaded.

git checkout v2017.3.1

Run the gradlew script. That script will use gradle, a software build tool, to compile the software we just downloaded. This script takes a while to run. Though, occasionally, I see this script freeze and hang. If that happens, it is safe to kill this and re-run it.

./gradlew build -PmakeSim

Copy the plugins we just compiled into our simulation plugins directory.

cp ./build/install/simulation/plugins/* \
    $HOME/wpilib/simulation/plugins/

Install model and world files 2018 simulation files have not yet been released (and the 2017 files were never shared either) but we can install the 2016 simulation worlds and models to give us something to work off. Download some 3D models for our simulation.

curl -o \
    $HOME/Downloads/models.zip \    https://usfirst.collab.net/sf/frs/do/downloadFile/projects.wpilib/frs.simulation.frcsim_gazebo_models/frs1160?dl=1

Unzip the model files into our $HOME/Downloads directory.

unzip $HOME/Downloads/models.zip -d $HOME/Downloads/

Copy the downloaded gazebo simulation models into our simulation directory.

cp -r $HOME/Downloads/frcsim-gazebo-models-4/models \
    $HOME/wpilib/simulation/

Copy the downloaded gazebo simulation worlds into our simulation directory.

cp -r $HOME/Downloads/frcsim-gazebo-models-4/worlds \
    $HOME/wpilib/simulation/

Download the official 2016 game arena world file to our simulation directory.

curl -o $HOME/wpilib/simulation/worlds/frc2016.world \
    "http://first.wpi.edu/FRC/roborio/release/simulation/downloads/frc2016.world"

Create a sample application In eclipse: Eclipse -> New -> Other -> Example Robot Java Project -> GearsBot -> Finish. Run

  1. FRCSim/Gazebo You only need to do this step once: Fire up frcsim (Gazebo) using the terminal.
frcsim

Wait until Gazebo has finished loading. Once Gazebo loads, insert the sample GearsBot robot provided by FRC. Gazebo -> Insert -> Models -> GearsBot Click somewhere in the world to place your model. Close everything open right now

Running Auton You only need to do this step once: install the 2016 field

curl -o $HOME/wpilib/simulation/worlds/frc2016.world \
    "http://first.wpi.edu/FRC/roborio/release/simulation/downloads/frc2016.world"

First open eclipse and run a eclipse 2016 prgm as a simulated robot deployment then type:

frcsim $HOME/wpilib/simulation/worlds/frc2016.world

then place the robot in the field then type in:

sim_ds

then click auton Then click enable You auton code should be simulated

Troubleshooting:

cd /directory/of/repository
ant jar
